BevelMite ABIS-B3.0 Beveling Machine Pneumatic

The new design BevelMite ABIS-3.0 is a perfect solution for lighter beveling and rounding work up to a depth of 6mm on mild steel and aluminium plates. The latest version machine has improved and improved pneumatic motor a redesigned flange head and tighter tolerance construction for reduced vibration and extended tool life. These handheld machines are highly portable and very maneuverable for creating smooth bevels and radius’s on complex parts and internal edges and holes.

Advantages:

  • Lightweight, portable design
  • High duty pneumatic tool
  • Easily switch between bevel angles or radius sizes by changing the cutting tool only.
  • Highly durable, patented carbide tooling design
  • Tooling suitable for mild steels, aluminium and hardened edges from laser and plasma cutting
  • Supplied in luxury protective hard case

Working Range:

  • Max Bevel Depth [mm] 6
  • Bevel Angles: 15, 22.5, 30, 37.5, 45, 52.5, 60
  • Rounding Radius: R2, R3, R4
  • Air Consumption: 0,62 M3/min

Machine comes with:

  • Bevel Mite ABIS-B3.0 Pneumatic
  • Protective Plastic Transportation case
  • (Tooling must be purchased separately)

Documentation:

Weight 1.8 kg
Dimensions 30 × 20 × 8 cm
